> R6DSMicro (1g) 2.4Ghz 10Ch S.Bus Receiver (DSSS + FHSS)
R6DSMicro (1g) 2.4Ghz 10Ch S.Bus Receiver (DSSS + FHSS) View larger

R6DSMicro (1g) 2.4Ghz 10Ch S.Bus Receiver (DSSS + FHSS)

RADR6DSM

Radiolink

Radiolink R6DSM, 2.4G 10 channels receiver, DSSS and FHSS spread spectrum working synchronously, 1 gram weight, SBUS and PPM signal support, use for Radiolink transmitters AT9, AT9S，AT10 and AT10II, is the best choice for racing drone.

More details

In stock This product is in stock

21,59 €


More info

Two signal working mode:

  • Blue/purple LED, SBUS signal , 10 channels totally.
  • Red LED always, PPM signal, 10 channels totally.

SBUS and PPM signal change:

Short press the ID SET switch two times within 1 second, the signal is changed from SBUS to PPM. The red LED indicates the PPM and blue/purple indicates SBUS.

Specifications
  • 1) Channels: 10 channels
  • 2) Working voltage: 4.8-6V
  • 3) Working current: 38-45mA（input voltage: 5V）
  • 4) Size: 15*13 MM
  • 5) Weight: 1g
  • 6) Detachable antenna
  • 7) 4096 section precision, 0.25us per section, servo anti-shake rudder.
  • 8) Control distance: about 600 meters, actually control distance depends on the environment.
Data sheet
