Xerun XR10 Pro Legacy Brushless Regler 150A, 2s LiPo

HW30112800

Hobbywing

Hobbywing Xerun XR10 Pro Legacy Brushless ESC 150A, 2s LiPo

More details

In stock This product is in stock

152,99 €


More info

Hobbywing XeRun XR10 Pro Legacy brushless speed controller

The XR10 Pro Legacy brings the legendary XR10 Pro look to the latest technical level! A modern 32-bit M4 processor ensures lightning-fast response times and high data processing, while the integrated intelligent fan only activates the cooling when required, thus increasing the service life. In addition, a built-in reverse polarity protection circuit protects against incorrectly connected batteries - for worry-free operation on race day.

Using the optional OTA Bluetooth module and the HW-Link app, all parameters can be conveniently set, firmware updated and real-time data (gas, voltage, temperature, RPM, etc.) monitored via cell phone. The data is stored in the OTA module - ideal for post-analysis after training or a run. Another new feature is the extended softening function, which helps to manage difficult track conditions!

Key features
  • 32-bit M4 processor: ultra-fast signal processing and expandable functions.
  • Intelligent fan function: fans only when needed for longer fan life.
  • Integrated reverse polarity protection
  • Real-time data logging via OTA: monitoring & recording
  • Softening function: sensitive response behavior on slippery surfaces}.
  • Wide range of applications: 1/10 on/off-road racing, drift, F1, rally
Specifications
  • Type: Brushless, Sensored ESC
  • Continuous/peak current: 150 A / 1000 A
  • Input voltage: 2S LiPo
  • BEC: Switching mode, 5.0-7.4 V, 5 A constant / 10 A peak
  • Motor limit: Touring = 4.5T, Buggy = 5.5T, 3650(540) 2-pole motor
  • Fan: Yes, intelligent start/stop function
  • Programming: OTA Bluetooth module (HW Link App)
  • Dimensions: 37.7 x 37.0 x 33.2 mm (with fan)
  • Weight: 94.2 g (with cables)
  • Applications: 1/10 On-Road & Off-Road Racing, 1/10 Drift/F1/Rally
Data sheet
  • Manufacturer : Hobbywing
